BIM-6601A Series VIS-NIR high resolution spectrometer, 315-1100nm optional

BIM-6601A Series VIS-NIR high resolution spectrometer, 315-1100nm optional, optical resolution ** to
0.06nm, Toshiba TCD1304, signal-to-noise ratio 300:1, dynamic range 300:1，A/D16bit

Description

BIM-6601A series high-resolution spectrometer adopts high-resolution optical-mechanical platform, with small size and very convenient to carry. The optimized optical path design optimizes the optical resolution to 0.06nm. Provides detectors with a wavelength response range of 315nm-1100nm. Within this wavelength range, users can obtain different optical resolutions and spectral response ranges by selecting different grating configurations. Use USB for data transmission and power supply, support RS232 communication, with high cost performance, suitable for application in industrial and scientific research fields.

Features

Cross-asymmetric C-T optical path structure

Interference filter eliminates second-order diffraction

SMA905 fiber interface, conveniently connected to other devices through optical fiber

Selectable wavelength range and optical resolution of 0.06nm-0.6nm

USB 2.0 data transmission and power supply

Support RS232 communication

Support multiple triggering methods

Optional enhanced cylindrical lens

Automatically read peak wavelength and bandwidth
